Electrix RC trucks

Circuit 1/10th Radio ControlStadium Truck

Click on the picture of the vehicle to get more information


Features


  • Completely ready to run with everything needed in one box
  • Nylon composite material gives it high strength and durability
  • Beginner friendly battery retaining system means there are no body clips to lose
  • Oil-filled shocks provide great handling that is also adjustable
  • Fully painted and decaled body out of the box means its ready to run and looks good
  • Standard components and mounts gives you a fully upgradeable truck
  • Two sets of crystals included means no crossed transmitters

Drive out loud with the Circuit™, a true ready-to-run vehicle that comes with absolutely everything included in one box. You read that right, everything’s included—right down to the AAs. You’ll love the powerful Dynamite® 20-turn motor and beginner-friendly snap-lock battery system.

Without a doubt, this rugged stadium truck is easy to use, but it’s also hard to abuse. It’s built from a strong, durable nylon composite material. You can customize the body with the included decal sheet. And thanks to the standard components and mounts, you can hop the Circuit up with additional bodies, tires, and parts and accessories.

Tech Notes


You will need...

Nothing - Everything is in the box!

Specifications


Type: 2WD Electric Off-Road Stadium Truck
Scale: 1/10
Length: 16.9 in (430mm)
Width: 12.9 in (328mm)
Wheelbase: 11.6 in (295mm)
Weight: 3.44 lb (1560 g)
Chassis: Molded composite
Suspension: 4-wheel independent long-travel
Drivetrain: 2WD with gear differential and slipper clutch
Tire Type: Front: Directional Rib Rear: Spike
Motor or Engine: Dynamite 20T
Speed Control: DYN 12T with forward and reverse
Radio: AM 27MHz
Servos: Analog
Gear Pitch: 48P
Wheel Size: 2.2 300 series
Kit/RTR: RTR everything included
Shock Type: Composite long-travel coil-over, oil-filled
Body: Custom screened truck
Ball Bearings: Complete
Minimum Age Recommendation: 14 years
Experience Level: No Experience Necessary
Is Assembly Required: No

Check Out These Videos On How To Work on Your Electrix RC Car



Parts Listing (This is a list of the most common parts required for repair)


Item ID Description Qty. Price
ECX1001 Painted Truck Body Red: Circuit 1
$29.99
ECX1005 Mounted Front Tire (2), Chr, Rib: Circuit 1
$19.99
ECX1006 Mounted Rear Tire (2), Chrome, Spike: Circuit 1
$19.99
ECX1017 Main Chassis: Circuit 1
$12.99
ECX1018 Front Suspension Arm Set 1
$4.99
ECX1019 Rear Suspension Arm Set 1
$4.99
ECX1020 Shock Tower Set 1
$5.99
ECX1022 Transmission Gear Set 1
$5.99
ECX1028 Servo Saver Set 1
$3.99
ECX1034 Rear Axle (2) 1
$7.99
ECX1038 Shock Parts Set 1
$3.99
ECX1043 Shock O-ring Set 1
$2.99
ECX1044 Hinge Pin Set 1
$4.99
ECX1045 Hinge Pin Retaining Screws (8) 1
$1.39
ECX1048 Body Clips (8) 1
$1.99
ECX1049 Wheel Pins (4) 1
$0.99
ECX1053 Foam Block: Circuit 1
$1.39
ECX1060 M4 Locknut (4) 1
$2.99
ECX1061 Screw Set (64) 1
$9.99
ECX1076 Spur Gear 1
$2.99
